 Linyang - An expert in PVC tarpaulin / PVC film industry since 2002

Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 1
Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 2
Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 3
Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 4
Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 5
Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 6
Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 7
Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 1
Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 2
Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 3
Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 4
Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 5
Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 6
Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - - 7

Clear Pvc Film Per Pantone Colors Or Customer-supplied Samples - -

Width Range:
40 ~ 260inch
Thickness Range:
0.12mm to 0.5mm
Softness Range:
18PHR to 78PHR (70PHR and above will be charged additionally)
Embossing:
Three patterns currently : 001 / 002 / 900
Color:
Per pantone colors or customer-supplied samples
Inquiry
Send your inquiry

Product details of the clear pvc film


Product Description

clear pvc film is made of good-quality materials and beautifully crafted by skilled worker. clear pvc film meets the future trends of diversified raw material, ecological processing and functional products. The product has been extensively used in the global market because of its remarkable advantages.


PVC calendaring film is made by calendaring process. Calendaring is the process of making the heated PVC plastic through the space between one or more horizontal rollers rotating in the opposite direction, so that the material can withstand extrusion and extension, and become a thin product with certain thickness, width and smooth surface. Polyvinyl chloride rolling film occupies an important position in plastic shed film. In addition, it is widely used in salt field tarpaulin cover, industrial packaging, electrical insulation, inflatable film products, lamp box advertising, engineering waterproof, daily necessities packaging and other aspects.


product-LINYANG-img
product-LINYANG-img


Features

bg

The reason why PVC calender is so widely used is that it has the following characteristics:


part.1
High tensile strength
The tensile strength of PVC film is up to 29MPa. PE film and EVA film were damaged in all the dust storms in northwest China, except PVC film
product-LINYANG-PVC Film Normal PVC film-img

part.2
Good insulation performance
As a covering material for agricultural greenhouses, glass has the best thermal insulation performance, followed by PVC calender film (with strong infrared absorption capacity) and PE film. In addition, at night, the thermal insulation performance of PVC film is not different from that of glass, which is very beneficial to the growth of crops.
product-LINYANG-img

part.3
Good transparency
The PVC calendering film is extruded by the mirror roller in the process of forming. The surface is highly polished, and the condensation of water droplets is less, so the transmittance is higher, which is beneficial to the photosynthesis of crops
product-LINYANG-img

part.4
Uniform thickness
Since the roll tube of PVC calender film is in the shape of medium drum and the middle roll crosses, the lower roll has prestrain and the roll surface has been finely ground, so the thickness accuracy is high
product-PVC Film Normal PVC film-LINYANG-img

part.5
Good adhesion performance
According to the need of use, PVC calender film can be used high frequency welding, thermal bonding and adhesive bonding methods, easy to use. In addition, according to the different USES of PVC film, the production formula and technological conditions can be changed to meet the requirements
product-LINYANG-PVC Film Normal PVC film-img

1
High tensile strength
The tensile strength of PVC film is up to 29MPa. PE film and EVA film were damaged in all the dust storms in northwest China, except PVC film
product-LINYANG-img-1

2
Good insulation performance
As a covering material for agricultural greenhouses, glass has the best thermal insulation performance, followed by PVC calender film (with strong infrared absorption capacity) and PE film. In addition, at night, the thermal insulation performance of PVC film is not different from that of glass, which is very beneficial to the growth of crops.
product-LINYANG-PVC Film Normal PVC film-img-1

3
Good transparency
The PVC calendering film is extruded by the mirror roller in the process of forming. The surface is highly polished, and the condensation of water droplets is less, so the transmittance is higher, which is beneficial to the photosynthesis of crops
product-LINYANG-img-1

4
Uniform thickness
Since the roll tube of PVC calender film is in the shape of medium drum and the middle roll crosses, the lower roll has prestrain and the roll surface has been finely ground, so the thickness accuracy is high
product-LINYANG-img-1

5
Good adhesion performance
According to the need of use, PVC calender film can be used high frequency welding, thermal bonding and adhesive bonding methods, easy to use. In addition, according to the different USES of PVC film, the production formula and technological conditions can be changed to meet the requirements
product-PVC Film Normal PVC film-LINYANG-img-1



Detailed product parameters

bg


DESCRIPTIONTECHNICAL REQUIREMENTS
UNIT
Normal PVC film
Color  Per    pantone colors or customer-supplied samples
Width    RangeNormal calendaring production line
inch20 ~    80inch
Thickness Rangemm 0.06mm    to 1.00mm
(max 1.50mm per embossing pattern 666)
Softness Rangephr18PHR    to 78PHR (70PHR and above will be charged additionally)
Embossing over    30 kinds of embossing patterns
Width RangeLarge calendaring production line
inch40    ~ 260inch
Thickness Rangemm 0.12mm    to 0.5mm
Softness Rangephr18PHR    to 78PHR (70PHR and above will be charged additionally)
Embossing Three    patterns currently :  001 / 002 / 900
Special Formula
The following standards can be fulfilled with our special formula, and will be charged additionally.
  EN-71    part I to part VIII
  ASTM963    / D3421-75 /D1790
  RoHS    test
  PAHs    test
  DEHP<3%,    DEHP<0.1%
  Japan    Toy Safety Standard
  Flammability    Test BS5852
3P <1000PPM PPMBBP,    DBP, DEHP
6P <1000PPMPPMPhthalate-free    <0.01%
(DINP, DNOP, DEHP, DIDP, BBP, DBP)
15P <1000PPM PPMPhthalate-free    <0.01%   (DBP,DMP,DEP,DEHP,DINP,BBP,DPP,DNOP,DNP,DIDP,DCHP,DPRP,DHP,DIBP,DIOP)
 — 30    > —10Degrees CelsiusFreeze    test
100 ~ 30000HRSAnti-ultraviolet    (UV) rays
  Anti-mildew
  Fire    retardant
< 10PPMPPMConsumption    of potassium permanganate
< 5PPMPPMPhenol
< 1PPMPPMVinyl-chloride
  Free    of AZO dye compound (amines-free)
  Free    of tin-organic
  Free    of nonylphenol
